Description
Bussmann JM70100-2CR
Edison Modular Fuse Block, Series: JM Series, 700 V, 100 A, 2 Pole, Class: J, Panel Mount
Additional Description: BUSS-JM70100-2CR Fuse block 700V 100A 2 pole
Catalog Description: Eaton Bussmann series JM modular fuse block, CR, 100 A, Two-pole, Class J, 200 kA, Box lug, 200 kAIC, 700 V
Specifications
| UNSPSC | 39121629 |
|---|---|
| Amperage Rating | 100 A |
| Class | aM/aR/gG/gL/gR/J |
| Class | J |
| Connection type | Box Lug |
| Dimensions | 3.69 in L x 2.57 in W x 3.02 in H |
| Fuse Diameter | 22 mm |
| Fuse Length | 58 mm |
| Material | Thermoplastic |
| Mounting type | DIN Rail |
| Mounting type | Panel |
| Number of Poles | 2 |
| Series | JM Series |
| Temperature Rating (Degrees F) | -40 to 120 deg C |
| Type | Modular |
| Voltage Rating | 700 V |
| Wire Size | 14 to 2 AWG Cu, 8 to 2 AWG Al |
