Description
Bussmann HTB-48I-R Fuse Holder
Bussmann Fuse Holder, Flame Retardant High Temperature High Profile Right Angle, Series: HTB, 250 VAC, 16/20 A, 1 Pole, Quick-Connect, Rear Panel Hex Nut Mount, 1-1/4 in Fuse Length, 1/4 in Fuse Dia, -55 to 85 deg C, For Use With: HTB Series Fuse, Thermoplastic, Black, 1.69 in L
Additional Description: BUSS-HTB-48I-R (N) FUSEHOLDER NON-CANCELABLE, NON-RETURNABLE
Catalog Description: 1/4" x 1-1/4" Knob Type RoHS Compliant Panel Mount Fuseholder, 1/4" Quick Connects/Solder, Right Angle Rear Terminal
Specifications
| UNSPSC | 39121624 |
|---|---|
| Amperage Rating | 16/20 |
| Amperage Rating | 16/20 A |
| Color | Black |
| Connection type | Quick-Connect |
| Dimensions | 1.69 in L |
| Fuse Diameter | 1/4 |
| Fuse Diameter | 1/4 in |
| Fuse Length | 1-1/4 |
| Fuse Length | 1-1/4 in |
| Material | Thermoplastic |
| Mounting type | Rear Panel Hex Nut |
| Number of Poles | 1 |
| Series | HTB |
| Suitable For Use With | HTB Series Fuse |
| Temperature Rating (Degrees F) | -55 to 85 |
| Temperature Rating (Degrees F) | -55 to 85 deg C |
| Type | Flame Retardant High Temperature High Profile Right Angle |
| Voltage Rating | 250 |
| Voltage Rating | 250 VAC |
