Description
Bussmann HTB-22M-R In-Line Fuse Holder
Bussmann Fuse Holder, In-Line Low Profile, Series: HTB, 250 VAC, 16 A, 1 Poles, Quick-Connect, Rear Panel Hex Nut Mount, 20 mm Fuse Length, 5 mm Fuse Dia, -55 to 85 deg C, For Use With: HTB Series Fuse, Thermoplastic, Black, 1.69 in L
Additional Description: BUSS-HTB-22M-R (N) FUSEHOLDER NON-CANCELABLE, NON-RETURNABLE
Catalog Description: 15A 250V 5mm x 20mm Knob Type RoHS Compliant Panel Mount Fuseholder, 3/16" Quick Connects, In-Line Rear Terminal
Specifications
| UNSPSC | 39121624 |
|---|---|
| Amperage Rating | 16 A |
| Color | Black |
| Connection type | Quick-Connect |
| Dimensions | 1.69 in L |
| Fuse Diameter | 5 mm |
| Fuse Length | 20 mm |
| Material | Thermoplastic |
| Mounting type | Rear Panel Hex Nut |
| Number of Poles | 1 |
| Series | HTB |
| Suitable For Use With | HTB Series Fuse |
| Temperature Rating (Degrees F) | -55 to 85 deg C |
| Type | In-Line Low Profile |
| Voltage Rating | 250 VAC |
