Description
Bussmann GMC-3.15-R
Bussmann Time Delay Fuse, Low Breaking Medium, Series: GMC, Non-Indicating, Non-Rejection, 3.15 A, 250 VAC, 100 A/10 kA Interrupt, 60 min, 2 min Response, Ferrule Terminal, Holder Mounting, Cylindrical Body, Single Element, Glass, 5.2 mm Dia x 20 mm L Body
Additional Description: BUSS-GMC-3.15-R GMC 3.15A BUSS FUSE
Catalog Description: 3.15A 250V 5mm x 20mm RoHS Compliant Glass, Medium Time Delay Fuse
Specifications
| UNSPSC | 39121607 |
|---|---|
| Amperage Rating | 3.15 A |
| Body Type | Cylindrical |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 100 A/10 kA |
| Material | Glass |
| Mounting type | Holder |
| Rejection/Non-Rejection | Non-Rejection |
| Response Time | 60 min, 2 min |
| Series | GMC |
| Terminal Type | Ferrule |
| Type | Low Breaking Medium |
| Voltage Rating | 250 VAC |
