Description
Bussmann FWP-450A High Speed Fuse
Bussmann High Speed Fuse, North American Style, Series: FWP, Indicating/Non-Indicating: Non-Indicating, 450 A, 250 VAC/VDC, 200 kAIC Interrupt, Blade End Terminal, Stud Mount, Cartridge Body Type, 2.5 in Dia x 7.09 in L Body Size
Additional Description: BUSS-FWP-450A BUSS HIGH SPEED FUSE
Catalog Description: Eaton Bussmann series FWP high speed fuse, 250 Vac/dc, 450A RMS, 200 kAIC Vac, 50 kAIC at 700 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
Specifications
| UNSPSC | 39121625 |
|---|---|
| Amperage Rating | 450 |
| Amperage Rating | 450 A |
| Body Type | Cartridge |
| Body Type | Cartridge Blade |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 200 kA at 700 VAC, 50 kA at 700 VDC |
| Interrupt Rating | 200 kAIC |
| Interrupt Rating | 50/200 |
| Material | Fiberglass |
| Mounting type | Bolt-In/Stud |
| Mounting type | Stud |
| Rejection/Non-Rejection | Non-Rejection |
| Series | FWP |
| Terminal Type | Blade |
| Terminal Type | Blade End |
| Terminal Type | Blade End x Blade End |
| Type | Fast Blow North American Style |
| Type | North American Style |
| Voltage Rating | 250 VAC/VDC |
| Voltage Rating | 700 |
