Description
Bussmann FWP-35A High Speed Fuse
Bussmann High Speed Fuse, North American Style, Series: FWP, Indicating/Non-Indicating: Non-Indicating, 35 A, 1400 VAC, 50/200 kAIC Interrupt, Blade End Terminal, Stud Mount, Cartridge Body Type, 0.813 in Dia x 4.375 in L Body Size
Additional Description: BUSS-FWP-35A BUSS HIGH SPEED FUSE
Catalog Description: Eaton Bussmann series FWP high speed fuse, 1400 Vac (FWS 8-15A), 2100 Vac (FWS 2-6A), 1000 Vdc (FWL/FWS 2-30A), 35A, Non Indicating, High speed fuse, Blade end X blade end, Stud
Specifications
| UNSPSC | 39121625 |
|---|---|
| Amperage Rating | 35 |
| Amperage Rating | 35 A |
| Body Type | Cartridge |
| Body Type | Cartridge Blade |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 200 kA at 700 VAC, 50 kA at 700 VDC |
| Interrupt Rating | 50/200 |
| Interrupt Rating | 50/200 kAIC |
| Material | Fiberglass |
| Mounting type | Stud |
| Rejection/Non-Rejection | Non-Rejection |
| Series | FWP |
| Terminal Type | Blade |
| Terminal Type | Blade End |
| Terminal Type | Blade End x Blade End |
| Type | Fast Blow North American Style |
| Type | North American Style |
| Voltage Rating | 1400 VAC |
| Voltage Rating | 700 |
