Description
Bussmann FWJ-300A High Speed Fuse
Bussmann High Speed Fuse, Fast Acting Semi-Conductor, Series: FWJ, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 300 A, 1000 VAC, 100 kAIC Interrupt, 45 to 1000 Hz, Blade End Terminal, Stud Mount, Cylindrical Body Type, Single Element, Ceramic, 2 in Dia x 5.768 in L Body Size
Additional Description: BUSS-FWJ-300A 300AMP 1000V AC SEMI-COND FUSE
Catalog Description: Eaton Bussmann series FWJ high speed fuse, 300A, 25 kAIC (35-200A), 100 kAIC (250-2000A), 50 kAIC at 800 Vdc (35-200A, 450-600A), None, High speed fuse, Blade end X blade end, Stud
Specifications
| UNSPSC | 39121625 |
|---|---|
| Amperage Rating | 300 |
| Amperage Rating | 300 A |
| Body Type | Cylindrical |
| Frequency Rating | 45 to 1000 |
| Frequency Rating | 45 to 1000 Hz |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 100 |
| Interrupt Rating | 100 kAIC |
| Material | Ceramic |
| Mounting type | Stud |
| Rejection/Non-Rejection | Non-Rejection |
| Series | FWJ |
| Terminal Type | Blade |
| Terminal Type | Blade End |
| Type | Fast Acting |
| Type | Fast Acting Semi-Conductor |
| Voltage Rating | 1000 VAC |
| Voltage Rating | 1000 VAC, 800 VDC |
