Description
Bussmann FWH-800A High Speed Fuse
Bussmann High Speed Fuse, North American Style, Series: FWH, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 800 A, 700 VAC/VDC, 50 kAIC Interrupt, Blade End Terminal, Stud Mount, Cartridge Body Type, Single Element, Fiberglass, 2.5 in Dia x 6.34 in L Body Size
Additional Description: BUSS-FWH-800A BUSS HIGH SPEED FUSE
Catalog Description: Eaton Bussmann series FWH high speed fuse, 700 Vac (UL), 690 Vac (IEC), 500 Vdc (2-100A), 500 Vac, 800A RMS, 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
Specifications
| UNSPSC | 39121625 |
|---|---|
| Amperage Rating | 800 |
| Amperage Rating | 800 A |
| Body Type | Cartridge |
| Body Type | Cylindrical |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 50 kAIC |
| Interrupt Rating | 50/200 |
| Material | Ceramic |
| Material | Fiberglass |
| Mounting type | Bolt-In/Stud |
| Mounting type | Stud |
| Rejection/Non-Rejection | Non-Rejection |
| Series | FWH |
| Terminal Type | Blade |
| Terminal Type | Blade End |
| Type | Fast Acting |
| Type | North American Style |
| Voltage Rating | 500 |
| Voltage Rating | 700 VAC/VDC |
| Voltage Rating | 700/690 VAC, 500 VAC/VDC |
