Description
Bussmann FWH-300A High Speed Fuse
Bussmann High Speed Fuse, North American Style, Series: FWH, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 300 A, 1000 VAC/800 VDC, 200 kAIC Interrupt, Blade End Terminal, Stud Mount, Cartridge Body Type, Single Element, Fiberglass, 1.5 in Dia x 4.34 in L Body Size
Additional Description: BUSS-FWH-300A BUSS HIGH SPEED FUSE
Catalog Description: Eaton Bussmann series FWH high speed fuse, 1000 Vac, 800 Vdc, 300A RMS, 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
Specifications
| UNSPSC | 39121625 |
|---|---|
| Amperage Rating | 300 |
| Amperage Rating | 300 A |
| Body Type | Cartridge |
| Body Type | Cylindrical |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 200 kAIC |
| Interrupt Rating | 50/200 |
| Material | Ceramic |
| Material | Fiberglass |
| Mounting type | Bolt-In/Stud |
| Mounting type | Stud |
| Rejection/Non-Rejection | Non-Rejection |
| Series | FWH |
| Terminal Type | Blade |
| Terminal Type | Blade End |
| Type | Fast Acting |
| Type | North American Style |
| Voltage Rating | 1000 VAC/800 VDC |
| Voltage Rating | 500 |
