Description
Bussmann FWH-20A14F High Speed Fuse
Bussmann High Speed Fuse, Series: FWH, Non-Indicating, 20 A, 500 V, 200 kA Interrupt, Class: AR, 42 to 62 Hz Frequency, Ferrule End Terminal, Holder Mounting, Cylindrical Body, 0.563 in Dia x 2 in L Body
Additional Description: BUSS-FWH-20A14F 20AMP 500V AC FERRULE 6.4 X 31.8MM
Catalog Description: Eaton Bussmann series FWH high speed fuse, 1000 Vac, 800 Vdc, 20A, 200 kAIC Vac, 50 kAIC at 500 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end
Specifications
| UNSPSC | 39121625 |
|---|---|
| Amperage Rating | 20 |
| Amperage Rating | 20 A |
| Body Type | Cartridge |
| Body Type | Cylindrical |
| Class | AR |
| Frequency Rating | 42 to 62 |
| Frequency Rating | 42 to 62 Hz |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 200 |
| Interrupt Rating | 200 kA |
| Interrupt Rating | 50/200 |
| Material | Fiberglass |
| Mounting type | Holder |
| Rejection/Non-Rejection | Non-Rejection |
| Series | FWH |
| Terminal Type | Ferrule |
| Terminal Type | Ferrule End |
| Terminal Type | Ferrule End x Ferrule End |
| Type | Fast Acting Semiconductor |
| Voltage Rating | 500 |
| Voltage Rating | 500 V |
