Description
Bussmann FWH-12A14F High Speed Fuse
Bussmann High Speed Fuse, Fast Acting, Series: FWH, Non-Indicating, 12 A, 500 V, 200 kA Interrupt, 45 to 1000 Hz Frequency, Ferrule End Terminal, Holder Mounting, Cylindrical Body, Ceramic, 14 mm Dia x 51 mm L Body
Additional Description: BUSS-FWH-12A14F 500V 12Amp S/COND FERRULE 14.3 X 50.8MM
Catalog Description: Eaton Bussmann series FWH high speed fuse, 1000 Vac, 800 Vdc, 12A, 200 kAIC Vac, 50 kAIC at 500 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end
Specifications
| UNSPSC | 39121625 |
|---|---|
| Amperage Rating | 12 |
| Amperage Rating | 12 A |
| Body Type | Cylindrical |
| Frequency Rating | 45 to 1000 |
| Frequency Rating | 45 to 1000 Hz |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 200 kA |
| Interrupt Rating | 50/200 |
| Material | Ceramic |
| Mounting type | Holder |
| Series | FWH |
| Terminal Type | Ferrule |
| Terminal Type | Ferrule End |
| Type | Fast Acting |
| Voltage Rating | 500 |
| Voltage Rating | 500 V |
