Description
Bussmann FWH-125A
Bussmann High Speed Fuse, North American Style, Series: FWH, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 125 A, 1000 VAC/800 VDC, 50/200 kAIC Interrupt, Bolted-Down Terminal, Stud Mount, Cartridge Body, Single Element, Fiberglass, 1.156 in Dia x 3.625 in L Body Size
Additional Description: BUSS-FWH-125A BUSS HIGH SPEED FUSE
Catalog Description: Eaton Bussmann series FWH high speed fuse, 1000 Vac, 800 Vdc, 125A, Non Indicating, High speed fuse, Stud
Specifications
| UNSPSC | 39121625 |
|---|---|
| Amperage Rating | 125 A |
| Body Type | Cartridge |
| Body Type | Cylindrical |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 50/200 kA |
| Interrupt Rating | 50/200 kAIC |
| Material | Ceramic |
| Material | Fiberglass |
| Mounting type | Stud |
| Rejection/Non-Rejection | Non-Rejection |
| Series | FWH |
| Terminal Type | Blade |
| Terminal Type | Bolted-Down |
| Type | Fast Acting |
| Type | North American Style |
| Voltage Rating | 1000 VAC/800 VDC |
| Voltage Rating | 500 VAC/VDC |
