Description
Bussmann DFJ-5
Bussmann High Speed Drive Fuse, Current Limiting, Series: DFJ, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 5 A, 150 VAC/VDC, 200/100 kAIC Interrupt, Class: J, Ferrule End Terminal, Stud Mount, Cylindrical Body Type, Silver Element, Melamine, 0.81 in Dia x 2.25 in L Body Size
Additional Description: BUSS-DFJ-5 DRIVE FUSE
Catalog Description: Eaton Bussmann series DFJ high speed fuse, 150 Vac/dc, 5A, None, High speed fuse, Ferrule end X ferrule end, Class J
Specifications
| UNSPSC | 39121625 |
|---|---|
| Amperage Rating | 5 A |
| Body Type | Cylindrical |
| Class | J |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 200/100 kAIC |
| Material | Melamine |
| Mounting type | Stud |
| Rejection/Non-Rejection | Non-Rejection |
| Series | DFJ |
| Terminal Type | Ferrule End |
| Type | Current Limiting |
| Voltage Rating | 150 VAC/VDC |
