Description
Bussmann CB20221009 Terminal Block Strips and Barrier Block
Bussmann Terminal Block Strips and Barrier Block, Closed Back, 300 VAC, 22 to 12 AWG Wire, 3/8 in Center Spacing, 9 in-lb Torque, 6 to 32 TPI Screw Connection, -40 to 105 deg C, Molded Thermoplastic, Black, 1.56 in L x 0.7 in W Dimensions
Additional Description: BUSS-CB20221009 TERMINAL BLOCK ASSEMBLY
Catalog Description: Single Row Terminal Blocks, 30A, industrial, Black, #6-32 TPI screw, Barrier end, Ten-pole, -40 to 105 deg C, Break down voltage 4100V, Closed back, 300V, #22 to 12 AWG (Copper), Molded thermoplastic, nickel plated brass SEMS screw, 9 lb-in
Specifications
| UNSPSC | 39121410 |
|---|---|
| Color | Black |
| Connection type | 6 to 32 TPI Screw |
| Dimensions | 1.56 in L x 0.7 in W |
| Material | Molded Thermoplastic |
| Temperature Rating (Degrees F) | -40 to 105 |
| Temperature Rating (Degrees F) | -40 to 105 deg C |
| Torque Rating | 9 |
| Torque Rating | 9 in-lb |
| Type | Closed Back |
| Voltage Rating | 300 |
| Voltage Rating | 300 VAC |
| Wire Size | 22 to 12 |
| Wire Size | 22 to 12 AWG |
