Description
Bussmann CB185-120 Circuit Breaker
Bussmann Automotive Circuit Breaker, Type III Switchable High Amp Waterproof, 48 VDC, 120 A, 3 kAIC Interrupt, Thermal Trip, 1 Pole, Push Button Actuator, 1/4-35 Stud, Flush Mount, 1.9 in L x 1.68 in W x 2.9 in H
Additional Description: BUSS-CB185-120 TYPE 3 SWITCHABLE W.P. C.B. 120 AMP AMP
Catalog Description: Eaton Bussmann series C.B.185 automotive circuit breaker, Switchable, 48 Vdc, 120A, 3 kAIC, Type III, High amp, Waterproof
Specifications
| UNSPSC | 39121609 |
|---|---|
| Actuator Type | Push Button |
| Actuator Type | Pushbutton |
| Amperage Rating | 120 |
| Amperage Rating | 120 A |
| Connection type | 1/4-35 Stud |
| Dimensions | 1.9 in L x 1.68 in W x 2.9 in H |
| Interrupt Rating | 3 |
| Interrupt Rating | 3 kAIC |
| Mounting type | Flush |
| Number of Poles | 1 |
| Trip Type | Thermal |
| Type | Type III Automotive High Amp Switchable Waterproof |
| Type | Type III Switchable High Amp Waterproof |
| Voltage Rating | 48 |
| Voltage Rating | 48 VDC |
