Description
Bussmann C14G10
Bussmann Fuse, Cylindrical Low Voltage Time Delay, Indicating/Non-Indicating: Non-Indicating, 10 A, 690 VAC, 50 A Interrupt, Class: GL/GG/C, 45 to 62 Hz, Ferrule End Terminal, Holder Mount, Cylindrical Body, Silver Plated Copper, 14 mm Dia x 51 mm L Body Size
Additional Description: BUSS-C14G10 CYLINDRICAL FUSE 14 x 51 10A GG 690V AC
Catalog Description: Eaton Bussmann series low voltage 14 x 51 mm cylindrical/ferrule fuse, rated at 690 Volts AC, 10 Amps, 80 kA Breaking capacity, class gG/gL, without indicator, compatible with a CH14 Modular fuse holder
Specifications
| UNSPSC | 39121626 |
|---|---|
| Amperage Rating | 10 A |
| Body Type | Cylindrical |
| Class | GL/GG/C |
| Frequency Rating | 45 to 62 Hz |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 50 A |
| Material | Silver Plated Copper |
| Mounting type | Holder |
| Terminal Type | Ferrule End |
| Type | Cylindrical Low Voltage Time Delay |
| Voltage Rating | 690 VAC |
