Description
Bussmann BK/HHB-Y408 Fuse Holder
Bussmann Fuse Holder, Universal, Series: HHB, 32 VDC, 30 A, 1 Pole, Copper Crimp Connection, 16 to 12 AWG Wire, In-Line Mounting, 7/8 to 1-1/4 in Fuse Length, 1/4 in Diameter Fuse, For Use With: Glass Tube Fuse, Nylon, Yellow, 0.53 in Dia Dimensions
Additional Description: BUSS-BK/HHB-Y408 BUSS FUSEHOLDER
Catalog Description: Universal Fuse Holder, 30A max, Supplemental, low voltage, low amperage control circuits, 16 To 12 AWG crimp, Bulk 100, 0.53 in Diameter X 2.42 in Length, in line, 1/4 in X 7/8 in to 1-1/4 in Fuse, 32V, Nylon body with tin-plated copper con
Specifications
| UNSPSC | 39121607 |
|---|---|
| Amperage Rating | 30 |
| Amperage Rating | 30 A |
| Color | Yellow |
| Connection type | Cooper Crimp |
| Connection type | Copper Crimp |
| Dimensions | 0.53 in Dia |
| Fuse Diameter | 1/4 |
| Fuse Diameter | 1/4 in |
| Fuse Length | 7/8 to 1-1/4 |
| Fuse Length | 7/8 to 1-1/4 in |
| Material | Nylon |
| Mounting type | In-Line |
| Number of Poles | 1 |
| Series | HHB |
| Suitable For Use With | Glass Tube Fuse |
| Type | Universal |
| Voltage Rating | 32 |
| Voltage Rating | 32 VDC |
| Wire Size | 16 to 12 |
| Wire Size | 16 to 12 AWG |
