Description
Bussmann ACK-120A
Bussmann Fusetron™ Fuse, Low Voltage One-Time Time Delay, Series: ACK, 120 A, 72 VDC, 10 kAIC Interrupt, 13 s Response, Stud Mount, Dual Element, Copper, 1.063 in Dia x 3.635 in L Body Size
Additional Description: BUSS-ACK-120A FUSETRON DUAL ELEMENT
Catalog Description: Eaton Bussmann series ACK fuse, Time-delay stud-mounted fuse, DC circuits protection for fork lift truck and battery chargers, 120 A, Dual, Non-indicating, 100 sec at 200%, 35 sec 300%, 13 sec at 500%, Standard
Specifications
| UNSPSC | 39121606 |
|---|---|
| Amperage Rating | 120 A |
| Interrupt Rating | 10 kA |
| Interrupt Rating | 10 kAIC |
| Material | Copper |
| Mounting type | Stud |
| Response Time | 13 s |
| Series | ACK |
| Type | Low Voltage |
| Type | Low Voltage One-Time Time Delay |
| Voltage Rating | 72 VDC |
