Description
Bussmann 63NHG00B-690 NH Fuse Link
Bussmann Fuse Link, Size 00 Dual Indicator Low Voltage, Series: NH Series, 690 VAC, 63 A, 45 to 62 Hz, Rated Breaking Capacity: 120 kA, Holder Mount, For Use with: NH Series Photovoltaic Fuse, Class C gG/gL Fuse, Ceramic, 78.5 mm L x 30 mm W
Additional Description: BUSS-63NHG00B-690 NH FUSE 63A 690V gG SIZE 00 IND
Catalog Description: Eaton Bussmann series low voltage NH Fuse, Live gripping lug, 690V, 63A, 120 kAIC, Combination fuse status indicator, fuse, Blade end connection, Class C gL/gG, Square-body with knife blade contact, Ceramic body - 63NHG00B-690
Specifications
| UNSPSC | 39121626 |
|---|---|
| Amperage Rating | 63 |
| Amperage Rating | 63 A |
| Dimensions | 78.5 mm L x 30 mm W |
| Frequency Rating | 45 to 62 |
| Frequency Rating | 45 to 62 Hz |
| Material | Ceramic |
| Mounting type | Holder |
| Rated Breaking Capacity | 120 |
| Rated Breaking Capacity | 120 kA |
| Series | NH Series |
| Suitable For Use With | Bussmann NH Size Photovoltaic Fuse |
| Suitable For Use With | NH Series Photovoltaic Fuse, Class C gG/gL Fuse |
| Type | Size 00 Class gG/gL Dual Indicator |
| Type | Size 00 Dual Indicator Low Voltage |
| Voltage Rating | 690 |
| Voltage Rating | 690 VAC |
