Description
Bussmann 4NHG000B-690 Fuse Link
Bussmann NH Fuse Link, Size 000 Dual Indicator Low Voltage, Series: NHG, 690 V, 4 A, 45 to 62 Hz, Rated Breaking Capacity: 120 kAIC, Holder Mount, For Use With: Class C/gG/gL Fuse, Ceramic, 79 mm L x 21 mm W x 51 mm H
Additional Description: BUSS-4NHG000B-690 (N) NH FUSE 4AMP 690V SIZE 000 GG MGL NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Eaton Bussmann series low voltage NH Fuse, Live gripping lug, 690V, 4A, 120 kAIC, Combination fuse status indicator, fuse, Blade end connection, Class C gL/gG, Square-body with knife blade contact, Ceramic body
Specifications
| UNSPSC | 39121626 |
|---|---|
| Amperage Rating | 4 |
| Amperage Rating | 4 A |
| Dimensions | 79 mm L x 21 mm W x 51 mm H |
| Frequency Rating | 45 to 62 |
| Frequency Rating | 45 to 62 Hz |
| Material | Ceramic |
| Mounting type | Holder |
| Rated Breaking Capacity | 120 kAIC |
| Series | NHG |
| Suitable For Use With | Class C/gG/gL Fuse |
| Type | Size 000 Dual Indicator Low Voltage |
| Voltage Rating | 690 |
| Voltage Rating | 690 V |
