Description
Bussmann 170M7595 High Speed Fuse
Bussmann High Speed Fuse, Type K, Series: 170M, Indicating, 2500 A, 1250 VAC, 1200 VDC, 125 kA Interrupt, Class: AR, Threaded Socket Terminal, Flush Mount, Square Body Type, 106.6 mm H x 120 mm W x 105 mm D Body Size
Additional Description: BUSS-170M7595 FUSE 2500A 1250V 4BKN/110 AR
Catalog Description: Fuse-link, high speed, 2500 A, AC 1250 V, 200 kA, size 4, 105 x 120 x 110 mm, aR, IEC, type K indicator
Specifications
| UNSPSC | 39121625 |
|---|---|
| Amperage Rating | 2500 |
| Amperage Rating | 2500 A |
| Body Type | Square |
| Class | AR |
| Indicating/Non-Indicating | Indicating |
| Interrupt Rating | 125 |
| Interrupt Rating | 125 kA |
| Mounting type | Flush |
| Series | 170M |
| Terminal Type | Threaded Socket |
| Type | Type K |
| Voltage Rating | 1250 VAC, 1200 VDC |
