Description
Bussmann 170M4810 Semiconductor Fuse
Bussmann High Speed Fuse, Semi-Conductor, Series: 170M, Non-Indicating, 100 A, 1000 V, 125 kA Interrupt, Class: aR, Blade End x Din 43-620 Blade End Terminal, DIN 43 620 Blade Style Mounting, Square Body, 5.433 in L x 0.315 in W x 2.087 in H Body
Additional Description: BUSS-170M4810 FUSE 100A 1000V 00/80 AR
Catalog Description: Eaton Bussmann series high speed square body fuse,100A,125 kAIC,Class aR,Blade end X Din 43-620 blade end,DIN 43 620,Standard,Clearing at 1000V: 6850,square body with centre-bolted tags (slotted),Top fuse status indicator,950,25W
Specifications
| UNSPSC | 39121625 |
|---|---|
| Amperage Rating | 100 |
| Amperage Rating | 100 A |
| Body Type | Square |
| Class | AR |
| Class | Class AR |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 125 |
| Interrupt Rating | 125 kA |
| Interrupt Rating | 150 |
| Mounting type | DIN 43 620 Blade |
| Mounting type | DIN 43 620 Blade Style |
| Series | 170M |
| Terminal Type | Blade End x Din 43-620 Blade End |
| Type | Semi-Conductor |
| Voltage Rating | 1000 |
| Voltage Rating | 1000 V |
| Voltage Rating | 700 |
