Description
Bussmann 100NHG00B-690 Fuse Link
Bussmann NH Fuse Link, Size 00 Dual Indicator Low Voltage, Series: NHG, 690 V, 100 A, 45 to 62 Hz Frequency, Rated Breaking Capacity: 120 kA, Holder Mounting, For Use With: Class C gG/gL Fuse, Ceramic
Additional Description: BUSS-100NHG00B-690 NH FUSE 100AMP 690V gG SIZE 00
Catalog Description: Eaton Bussmann series low voltage NH Fuse, Live gripping lug, 690V, 100A, 120 kAIC, Combination fuse status indicator, Blade end connection, Class C gL/gG, square-body with knife blade contact, Silver plated copper contact plate
Specifications
| UNSPSC | 39121409 |
|---|---|
| Amperage Rating | 100 |
| Amperage Rating | 100 A |
| Frequency Rating | 45 to 62 |
| Frequency Rating | 45 to 62 Hz |
| Material | Ceramic |
| Mounting type | Holder |
| Rated Breaking Capacity | 120 kA |
| Series | NHG |
| Suitable For Use With | Class C gG/gL Fuse |
| Type | Size 00 Dual Indicator Low Voltage |
| Voltage Rating | 690 |
| Voltage Rating | 690 V |
