Binder 99-9136-50-12 Snap-In IP67 (miniature) Female panel mount connector, Contacts: 12, unshielded, solder, IP67, VDE

No reviews yet Write a Review
$20.84
Binder 99-9136-50-12 Snap-In IP67 (miniature) Female panel mount connector, Contacts: 12, unshielded, solder, IP67, VDE | American Cable Assemblies
Binder 99-9136-50-12 Snap-In IP67 (miniature) Female panel mount connector, Contacts: 12, unshielded, solder, IP67, VDE
Binder 99-9136-50-12 Snap-In IP67 (miniature) Female panel mount connector, Contacts: 12, unshielded, solder, IP67, VDE
SKU:
BN99-9136-50-12
MPN:
99-9136-50-12
Availability:
Lead time - Stock items ship 1-2 Days
Minimum Purchase:
1 unit
Current Stock:
Product Type:
Snap-In, series 720, Connectors for medical applications
Numbers of contacts:
12
$20.84

Frequently Bought Together:

Binder 99-9136-50-12 Snap-In IP67 (miniature) Female panel mount connector, Contacts: 12, unshielded, solder, IP67, VDE | American Cable Assemblies
Inc. Tax
Ex. Tax

Description

General Features
Part no. 99 9136 50 12
Connector design Female panel mount connector
Version Connector socket straight
Connector locking system snap-in
Termination solder
Degree of protection IP67
Cross-sectional area max. 0.25 mm² / AWG 24
Temperature range from/to -25 °C / 85 °C
Mechanical operation > 500 Mating cycles
Weight (g) 6.254
Customs tariff number 85369010

Electrical Parameters
Rated voltage 60 V
Rated impulse voltage 800 V
Rated current (40 °C) 2.0 A
Insulation resistance ? 10¹? ?
Pollution degree 2
Overvoltage category II
Insulating material group II
EMC compliance unshielded
Material
Housing material PA
Contact body material PA (UL94 HB) red
Contact material CuSn (bronze)
Contact plating Au (gold)
