Description
Note: All Binder product sales are final. Non-cancelable, non-returnable (NCNR).
| Part no. | 99 5712 00 03 |
|---|---|
| Connector design | Adapter |
| Version | Adapter |
| Connector locking system | Central bolt |
| Termination | pluggable |
| Degree of protection | IP65 |
| Cross-sectional area | max. 0.34 mm² / AWG 22 |
| Temperature range from/to | -25 °C / 85 °C |
| Mechanical operation | > 50 Mating cycles |
| Weight (g) | 22.95 |
| Customs tariff number | 85369010 |
| Rated voltage | 60 V |
|---|---|
| Rated impulse voltage | 8000 V |
| Rated current (40 °C) | 4.0 A |
| Insulation resistance | ? 10¹? ? |
| Pollution degree | 3 |
| Overvoltage category | II |
| Insulating material group | II |
| EMC compliance | unshielded |
| Contact body material | PA (UL94 HB) |
|---|---|
| Contact material | CuSn (bronze) / CuZn (brass) |
| Contact plating | Ni (nickel) |
| REACH SVHC | CAS 7439-92-1 (Lead) |
| SCIP number | 6dd3a9f3-f3e8-471d-b57f-a49b6ce142e7 |
