Binder 77-3429-3406-50004-0200 Connecting Cables Male cable connector - female cable connector, Contacts: 4, unshielded, moulded on the cable, IP67, UL, PUR, black, 4 x 0.34 mm², 2 m

No reviews yet Write a Review
$21.68
Binder 77-3429-3406-50004-0200 Connecting Cables Male cable connector - female cable connector, Contacts: 4, unshielded, moulded on the cable, IP67, UL, PUR, black, 4 x 0.34 mm², 2 m | American Cable Assemblies
Binder 77-3429-3406-50004-0200 Connecting Cables Male cable connector - female cable connector, Contacts: 4, unshielded, moulded on the cable, IP67, UL, PUR, black, 4 x 0.34 mm², 2 m
Binder 77-3429-3406-50004-0200 Connecting Cables Male cable connector - female cable connector, Contacts: 4, unshielded, moulded on the cable, IP67, UL, PUR, black, 4 x 0.34 mm², 2 m
SKU:
BN77-3429-3406-50004-0200
MPN:
77-3429-3406-50004-0200
Availability:
Lead time - Stock items ship 1-2 Days
Minimum Purchase:
1 unit
Current Stock:
Product Type:
series 765, Automation Technology - Sensors and Actuators
Numbers of contacts:
4
Cable length:
2 m
$21.68

Frequently Bought Together:

Binder 77-3429-3406-50004-0200 Connecting Cables Male cable connector - female cable connector, Contacts: 4, unshielded, moulded on the cable, IP67, UL, PUR, black, 4 x 0.34 mm², 2 m | American Cable Assemblies
Inc. Tax
Ex. Tax

Description

Complementing the wide range of cable and flange connectors, connecting cables with screw locking are available in IP67/68 and IP69K to precisely meet customer requirements. The cable length can be 1m or 2m as standard. To extend the range of applications and enable flexible signal distribution, we offer M8x1 and M12x1 duo connectors moulded onto the cable as well as M8 and M12 compatible two-way distributors.
General Features
Part no. 77 3429 3406 50004-0200
Alternative part no.: 79 5009 20 04
Notice
Please note that, due to the change from the old to the new order number, there may be deviations in the technical specifications. For questions about product details, please use the ‘Contact Customer Service’ form on the right.
More
Connector design Male cable connector - female cable connector
Cable length 2 m
Version Connecting cable
Connector locking system screw
Termination moulded on the cable
Degree of protection IP67
Cross-sectional area 0.34 mm² / AWG 22
Temperature range from/to -25 °C / 85 °C
Mechanical operation > 100 Mating cycles
Weight (g) 119
Customs tariff number 85444290

Electrical Parameters
Rated voltage 60 V
Rated impulse voltage 800 V
Rated current (40 °C) 4.0 A
Pollution degree 3
Overvoltage category II
Insulating material group II
EMC compliance unshielded
Material
Contact body material PUR
Contact material CuZn (brass)
Contact plating Au (gold)
REACH SVHC CAS 7439-92-1 (Lead)
SCIP number 75530375-4f50-4cfd-b021-ca1be2b4af92
