Description
Specifications
| RoHS Compliant | Yes |
|---|---|
| Package | Spool |
| Series | - |
| Product Status | Active |
| Voltage | 300 V |
| Features | Drain Wire |
| Wire Gauge | 18 AWG |
| Operating Temperature | -20°C ~ 105°C |
| Length | 100.0' (30.5m) |
| Cable Type | Multi-Conductor |
| Usage | - |
| Number of Conductors | 2 |
| Conductor Strand | 19/30 |
| Jacket Color | Slate |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Ratings | - |
| Conductor Material | Copper, Tinned |
| Jacket (Insulation) Diameter | 0.247" (6.27mm) |
| Jacket (Insulation) Thickness | 0.0380" (0.965mm) |
| Shield Type | Foil |
| Datasheet |  View (PDF) |
