Description
Specifications
| RoHS Compliant | Yes |
|---|---|
| Package | Spool |
| Series | - |
| Product Status | Active |
| Voltage | 150 V |
| Features | Drain Wire |
| Wire Gauge | 24 AWG |
| Operating Temperature | -25°C ~ 125°C |
| Length | 1000.0' (304.8m) |
| Cable Type | Multi-Pair |
| Usage | - |
| Number of Conductors | 6 (3 Pair Twisted) |
| Conductor Strand | #7/32 |
| Jacket Color | Slate |
| Jacket (Insulation) Material | Polyvinylidene Fluoride (PVDF) |
| Ratings | - |
| Conductor Material | Copper, Tinned |
| Jacket (Insulation) Diameter | 0.199" (5.06mm) |
| Jacket (Insulation) Thickness | 0.0110" (0.279mm) |
| Shield Type | Foil |
| Datasheet |  View (PDF) |
