Description
Specifications
| RoHS Compliant | Yes |
|---|---|
| Package | Spool |
| Series | - |
| Product Status | Active |
| Voltage | 300 V |
| Features | Drain Wire |
| Wire Gauge | 28 AWG |
| Operating Temperature | -20°C ~ 80°C |
| Length | 1000.0' (304.8m) |
| Cable Type | Multi-Pair |
| Usage | Communication, Control |
| Number of Conductors | 12 (6 Pair Twisted) |
| Conductor Strand | #7/36 |
| Jacket Color | Slate |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Ratings | UL Style 2464 |
| Conductor Material | Copper, Tinned |
| Jacket (Insulation) Diameter | 0.275" (6.99mm) |
| Jacket (Insulation) Thickness | 0.0350" (0.889mm) |
| Shield Type | Foil, Braid |
| Datasheet |  View (PDF) |
